KOMATSU PC290 LCI-11
- Share
Year
2024
Manufacturer
Komastu
Model
PC290 LCI-11
Condition
New
Location
Ontario
Expect first-to-last-pass accuracy in a stable and productive machine across multiple applications, without the transportation-permit headaches of bigger machines. The 5th intelligent machine control excavator in the Komatsu family, the PC290LCi-11 leverages proven technology that minimizes over-excavation and leaves nothing behind but a clean and accurate graded surface.
Large high-strength steel castings on the boom, arm and bucket link.
Closed-center load-sensing hydraulics for precise, fine control.
Large displacement high-efficiency pumps provide optimal attachment flow.
Large, spacious, quiet cab featuring standard air suspension seat.
Large high-strength steel castings on the boom, arm and bucket link.
Closed-center load-sensing hydraulics for precise, fine control.
Large displacement high-efficiency pumps provide optimal attachment flow.
Large, spacious, quiet cab featuring standard air suspension seat.
Engine
| Model | Komatsu SAA6D107E-3* |
| Type | Water-cooled, 4-cycle, direct injection |
| Aspiration | Komatsu variable geometry turbocharged, aftercooled, cooled EGR |
| Number of cylinders | 6 |
| Bore | 4.21 in |
| Stroke | 4.88 in |
| Piston displacement | 408 in³ |
| Horsepower: | |
| SAE J1995 : Gross | 213 HP |
| ISO 9249/SAE J1349 : Net | 196 HP |
| Rated rpm | 2,050 rpm |
| Fan drive type | Mechanical |
| Governor | All-speed control, electronic. |
| *EPA Tier 4 Final emissions certified |
Hydraulics
Type: HydrauMind (Hydraulic Mechanical Intelligence New Design) system, closed-center system with load sensing valves and pressure compensated valves
| Number of selectable working modes | 6 |
| Main pump: | |
| Type | Variable displacement piston type |
| Pumps for | Boom, arm, bucket, swing, and travel circuits |
| Maximum flow | 126.5 US gpm |
| Supply for control circuit | Self-reducing valve |
| Hydraulic motors: | |
| Travel | 2 x axial piston motor with parking brake |
| Swing | 1 x axial piston motor with swing holding brake |
| Relief valve setting: | |
| Implement circuits | 5,400 psi |
| Travel circuit | 5,400 psi |
| Swing circuit | 4,190 psi |
| Pilot circuit | 470 psi |
| Hydraulic cylinders: | |
| Number of cylinders | Bore x Stroke x Rod Diameter |
| Boom / 2 | 5.5 x 51.2 x 3.9 in |
| Arm / 1 | 5.9 x 64.3 x 4.3 in |
| Bucket / 1 | 5.5 x 39.7 x 3.9 in |
Drives and Brakes
| Steering control | Two levers with pedals |
| Drive method | Hydrostatic |
| Maximum drawbar pull | 56,000 lbs. |
| Gradeability | 70%, 35° |
| Maximum travel speed: (Auto-Shift) | |
| High | 3.4 mph |
| Mid | 2.5 mph |
| Low | 1.9 mph |
| Service brake | Hydraulic lock |
| Parking brake | Mechanical disc brake |
Swing System
| Drive method | Hydrostatic |
| Swing reduction | Planetary gear |
| Swing circle lubrication | Grease-bathed |
| Service brake | Hydraulic lock |
| Holding brake/Swing lock | Mechanical disc brake |
| Swing speed | 10.5 rpm |
| Swing torque | 64,292 ft.-lbs. |
Undercarriage
| Center frame | X-frame |
| Track frame | Box-section |
| Seal of track | Sealed track |
| Track adjuster | Hydraulic |
| Number of shoes | 48 each side |
| Number of carrier rollers | 2 each side |
| Number of track rollers | 8 each side |
Coolant & Lubricant Capacity (Refilling)
| Fuel tank | 105.7 US gal |
| Coolant | 9.5 US gal |
| Engine | 6.1 US gal |
| Final drive, each side | 2.1 US gal |
| Swing drive | 1.9 US gal |
| Hydraulic tank | 34.9 US gal |
| Hydraulic system | 66.8 US gal |
| DEF tank | 6.1 US gal |
Operating Weight (Approximate)
Operating weight includes 20 ft. 2 in one-piece boom, 10 ft. 6 in arm, SAE heaped 2.13 yd3 bucket, rated capacity of lubricants, coolant, full fuel tank, operator, and standard equipment..
| Triple-Grouser Shoes | Operating Weight: | Ground Pressure |
| 28 in | 70,702 lbs. | 7.48 psi |
| 31.5 in | 71,540 lbs. | 6.63 psi |
| 33.5 in | 72,091 lbs. | 6.28 psi |
Sound Performance
| Exterior – ISO 6395 | 104 dB(A) |
| Operator – ISO 6396 | 70 dB(A) |
Cab
- ROPS cab (ISO12117-2)
- High back air suspension seat, with heat
- Operator Protective Guard (OPG) Level 1 top guard
- Large LCD high resolution color monitor
- Automatic climate control
- Retractable seat belt (76mm width) with indicator
- Two 12V accessory outlets
- Rearview mirrors, right hand and left hand side
- Rearview monitoring system (1 camera)
- Travel alarm
- Proportional joystick control levers
- Operator identification system
- Hydraulic lock lever
- Skylight
Engine
- Komatsu SAA6D107E-3 Tier 4 Final
- Dry type air cleaner, double element
- Fuel pre-filter with water separator
- Fuel high efficiency filter
- Automatic engine warm up system
- Programmable auto-idle shut down
- Overheat prevention system
- Turbocharger protection system
Hydraulic controls
- Pattern change control valve (ISO to BH control)
- Working mode selection system (6 Modes)
- Dual pump, Closed Center Load Sensing System (CLSS)
- Auto-deceleration system
- Power max system
- Boom and arm holding valves
- Arm quick return valve
Technology
- Komtrax level 5.0
- Intelligent Machine Control
- 264 mm (10.4") IMC color monitor with USB
- Multi-band UHF/915SS radio
- Auto grade assist
- Auto stop control
- Minimum distance control
- Bucket angle hold control
- Provision for auto tilt control*
- In field design - 2D simple surface
Electrical system
- Batteries, large capacity (2 x 12Volt)
- Battery master disconnect switch with lockout tagout
- Alternator (90Amp, 24Volt)
- Starter motor (5.5 kW)
- Secondary engine shut off switch
- Working lights (1 front RH side / 1 boom LH side)
Booms and arms
- 6150 mm (20'2") boom assembly
- 3200 mm (10'6") arm assembly
- Boom foot, boom nose, & arm end steel castings
Undercarriage and work equipment
- 800 mm (31.5") triple grouser track shoes
- 8 track / 2 carrier rollers (each side)
- Hydraulic track adjusters (each side)
- Track guiding guards, center section (each side)
- Counterweight, 5200 kg (11,464 lbs.)
- Object handling H-link
- Tie off points (ISO 14567) - Work eq. and upper structure
Guards and covers
- Revolving frame deck guards
- Revolving frame undercovers - standard
- Track frame swivel guard
- Pump / engine room partition
- Turbocharger exhaust manifold cover
- Dust net for radiator and hydraulic oil cooler
- Slip resistant foot plates
- Tool free access to engine and aftertreatment
- Left and right side hand rails
Drive and brake system
- Three speed travel with auto shift
- Double reduction type final drive
- Triple labyrinth final drive seals
*IMU for auto-tilt control and one way/two way flow hyd control unit required for operation
**With revolving frame reinforcements, Only available with super long fronts
For a complete list of available attachments, please contact your local Komatsu distributor.
Cab
- Sunvisor
- Rainvisor
- Working lights, two additional cab mounted
- Straight travel pedal
Hydraulic controls
- One way/two way flow hyd control unit
Variable pressure and flow, return filter, & accumulator
Technology
- Komvision (4 camera system)
- IMU for auto tilt control
Booms and arms
- 6150mm (20'2") boom assembly with +1 attach piping
- 3200mm (10'6") arm assembly with +1 attach piping
- 3500mm (11'6") arm assembly
- 3500mm (11'6") arm assembly with +1 attach piping
Undercarriage and work equipment
- 850mm (33.5") triple grouser track shoes
- 700mm (28") triple grouser track shoes
- Track roller guards, full length (each side)
Guards and covers
- Cab full front guard, OPG Level 1
- Cab full front guard, OPG Level 2
- Cab top guard, OPG Level 2
- Revolving frame undercovers - heavy duty
*IMU for auto-tilt control and one way/two way flow hyd control unit required for operation
**With revolving frame reinforcements, Only available with super long fronts
For a complete list of available attachments, please contact your local Komatsu distributor.
