2023 LINK-BELT TCC-2500
- Share
Model
TCC-2500
Condition
New
| Base Rating | 250 Ton (227mt) |
| Main Boom | Seven Section Formed Boom |
| Length (min-max) | 43.7'-223' (13.3m-68m) |
| Telescope System | Pin & Latch |
| Max Tip Height | 346' (105.4m) |
| Engine Make & Model | Cummins QSL 9 |
| Horsepower | 320hp(239kW) @ 1,800rpm |
| Maximum Line Pull | 28,582lbs (12,965kg) |
| Max Line Speed No Load | 404 f/min (123.1 m/min) |
| Standard Upper Weights | 154,000lbs (69.8mt) |
| Standard Lower Weights | 44,000lbs (19.9mt) |
| Main Transport Load | 107,156lbs (48,605kg) |
| Overflow Loads | 7 |
