2023 LINK-BELT TCC-800
- Share
Model
TCC-800
Condition
New
| Base Rating | 55 Ton @ 9' (51mt @ 3m) |
| Main Boom | Four Section Formed Boom |
| Length (min-max) | 36'-115' (11.2m-35.1m) |
| Telescope System | Full Power |
| Attachment Option 3 | N/A |
| Max Tip Height | 170' (51.9m) |
| Engine Make & Model | Cummins QSB 6.7L |
| Horsepower | 215hp (160kW) @ 1,800rpm |
| Maximum Line Pull | 17,084lbs (7,749.1kg) |
| Max Line Speed No Load | 549fpm (167.5mpm) |
| Standard Upper Weights | 25,000lbs (11,340kg) |
| Standard Lower Weights | N/A |
| Main Transport Load | 99,850lbs (45 291kg) |
| Overflow Loads | 1 for XL Ctwt package |
